Features
Creative front layout of function buttons(video,photo,audio),conforms
to ergonomic design,make simple and high efficiency operation during
law enforcement and other inspection usage;
Use advanced Ambarella A12 chipset,
full-HD 1296P 30fps camera,H.264 encoding;
Use 36 million pixels CMOS camera,support max
2304x1296P video resolution and 8640x4752 photo resolution;
Support 4G TD-SCDMA / EVDO / WCDMA / LTE-TDD FDD,
Support GPS positioning / WIFI / Bluetooth /
Support remote live streaming through wireless network,
Support platform software replay or review recorded video and photo through wireless network;
Support PTT two ways talking;
Support night vision and laser positioning;
Specification
|
Chipset
|
Ambarella A12
|
|
System
|
RTOS + Linux dual system
|
|
Network
|
4G FDD/TDD LET, 5-mode, WCDMA/TD-SCDMA;
2G/GSM(Band2/3/5/8);
TD-SCDMA(Band34/39);
WCDMA(Band1/2/5);
LTE-TDD(Band38/39/40/41);
LTE-FDD(Bnad1/3);EVDO(BC0)
|
|
Built-in Wifi,802.11b/g/n/ac,2.4G/5G Dual Band
|
|
Built-in Bluetooth 4.0
|
|
Remote live view through wireless network
|
|
Support remote live streaming through wireless network
|
|
Support platform software replay or review recorded video and photo through wireless network
|
|
Position
|
Support GPS / Beidou
/ Galileo(optional) / Glonass(optional);
Support position real-time tracking and track playback
|
|
Video Resolution
|
2304x1296P(30fps),1920x1080P(30fps),
1280x720(30fps or 60fps selectable)
|
|
Video Compression
|
H.264 encoding,MPG4
|
|
Video Clip
|
5min,10min,15min configurable
|
|
Photo Resolution
|
Max 36 million pixels;
Max Actual effective pixels 8640x4752
|
|
Snap Shot
|
Capture Photos During Video Recording
|
|
Burst
|
1/3/5/20 shot burst picture taking
|
|
Recording
Format
|
Video:MP4,Audio:AAC2./MP3,Photo:JPG
|
|
Lens Angle
|
Super wide field view angle,
Diagonal / Horizontal / Vertical:175°/132°/66°
|
|
Night Vision
IR Light
|
8 pcs IR Light
Auto open infrared lamp,distinguish people facial feature 10m Away,identify people contour 20m away
|
|
Laser
Positioning Light
|
Fix target when photograph,
especially helpful under dark environment
|
|
Flash Light
|
High brightness LED supplement light
|
|
Microphone
|
Build-in high quality double microphone
|
|
PTT Talking
|
Support two way radio between different devices;
Support two way radio between device and platform
|
|
Recording Storage
|
1GB DDR3 RAM,
Standard 32GB built-in ROM(TF Card)
(64G / 128G TF Card Optional,Max. 2TB)
|
|
Recording Capacity
|
Recording time more than 8 hours,
Together with 3000 pcs pictures under 8MP(32G ROM)
|
|
Screen
|
2.0 inch High Light TFT LCD(320x240)
|
|
Recording/Play
|
Browse and replay video,sounds,photos;
Support 4X digital zoom;
Support Max.64X fast forward and rew
|
|
Password Protect
|
To set an administrator password to allow deletion via software.User can only view but can not delete it.
|
|
Water Mark
|
User ID,time and date stamp imbedded into video
|
|
SOS Key
|
Sending emergency alarm to platform immediately
|
|
Tips Sound
|
Sound occur in case power shortage
or full of memory storage
|
|
Battery
|
Li-battery,3600mAh (4.35V)
|
|
Working Hours
|
8 hours 720P,5 hours when 4G,240 hours standby
|
|
Charging Time
|
3 Hours
|
|
Free Fall Down
|
Height 3200mm to cement floor still working,
each side fall down 1 time
|
|
Protection
|
IP67
|
|
Data Connection
|
Mini USB 2.0, BT4.0
|
|
Charger
|
DC 5V,1000mA adapter,USB cable
|
|
Working Temperature
|
-40℃-60℃
|
|
Working humidity
|
40%-90%
|
|
Size
|
87mm(L)×58mm(W)×34mm(H)
|
|
Weight
|
150g
|
|
Standard Accessories
|
USB Cable,AC Charger,Metal Clip,User Manual,CD
|
